S-Max Sella
S-Max Sella stairclimber from AAT Asia for spiral and narrow stairs was developed due to the fact that stairs in buildings are rarely designed or built in such a way that they are accessible for people with reduced mobility. Indeed in many cases they represent a great barrier.
A stair climber designed to be truly transportable, safe and comfortable which has proved its worth in a wide range of circumstances including rheumatism, arthritis, muscular dystrophy, cystic fibrosis, cerebral palsy, stroke, spina bifida, parkinsons, MND, multiple sclerosis, spinal injury, amputee and for senior citizens.
A stair climber designed to be truly transportable, safe and comfortable which has proved its worth in a wide range of circumstances including rheumatism, arthritis, muscular dystrophy, cystic fibrosis, cerebral palsy, stroke, spina bifida, parkinsons, MND, multiple sclerosis, spinal injury, amputee and for senior citizens.
Book A Free Demo
The S-Max Sella — The Versatile Stair Climber
ComfortStep ( An additional feature)- The combination of plesanant driving characteristics and a comfortable climbing experience characterized by low vibrations.
For transportation, the s-max sella can be easily assembled and disassembled.
Technology you can trust :-
- LED's for safe operation in low-light situations
- Engine immobilizer to prevent unauthorized use
- No damage on stairs and floor coverings
- Automatic braking function when descending
- Particularly suitable for narrow stairs
Comfort Step
- Soft Touching Down
- Low-Vibration Climbing
- Comfortable Climbing
- With Integrated battery Display
- Can be Turned On at All Times
S-Max Sella Technical Data
| s-max sella 135 | s-max sella 160 | |
|---|---|---|
| Total weight approved (1) | 170 kg | 195 kg |
| Max. weight of the person | 135 kg | 160 kg |
| Climbing speed | adjustable | |
| Steps per minute (2) | 5 — 20 | 8 — 23 |
| Range with one charge of the batteries (2) | approx. 26 levels (equates 390 steps) |
approx. 20 levels (equates 300 steps) |
| Max. height of step | extended | 220 I 235 mm | |
| Width | 495 mm | |
| Depth | 320 mm | |
| Height min. | max. | 1150 | 1550 mm | |
| Batteries | 2 x 12 V / 3,3 Ah | |
| Direct current motor | 24 V / 200 W | |
| Weight, climbin unit | 15,8 kg | 16,9 kg |
| Weight, handle- and seat unit | 14,8 kg | |
| Weight, both arm rests | 1,2 kg | |
| Weight, battery pack | 3,3 kg | |
| Total weight | 34,8 kg | 35,9 kg |
(1) Please note the maximum load stipulated by the wheelchair manufacturer.
(2) The climbing speed as well as the range with one charge of the batteries is reduced if the ComfortStep is activated.
Download Brochure S-Max Sella
